Note：

By default, the three motherboard working modes of Venture XL are as follows

Spider_Pro:

USB to CANBUS Bridge Mode, No bootloader, with 120R resistor (the jumper cap next to MCU_CAN is installed by default)
It provides CAN2, which is used to connect SB_Combo and Cartographer, hardware link reference here:
klipper configuration is as follows:

SB_Combo:

CANBUS, 1000000, No bootloader, with 120R resistor (120R jumper pad is enabled by default)
klipper configuration is as follows:

SB_Combo_V2_menuconfig_nobootloader_CAN

Cartographer:

CANBUS, 1000000, without 120R resistor

Mechanical Parts
